| Antenna Product Lines |
|
2.0 to 30.0 MHz Broadband Omni -Directional NVIS Antenna
Roof Top and Tactical Models
The
MODEL 1942 compact, NVIS antenna is available in two
separate models. Both models have an RF Power Handling
Capacity of 1 kW CW / 2 kW PEP.
The 1942-RT (Roof Top NVIS) is designed for a
semi-permanent roof top installation. It’s small footprint
(less than 50 ft. square) allowing mounting on most all flat
roof commercial buildings. The antenna is designed to be
mounted on existing roofs and does not require roof
penetrations for installation.
Both antennas have stainless steel elements
and ground radials. Both have snap together aluminum mast
sections that can be assembled on the ground and easily
pivoted up to the erect position. Both systems utilize guy
wires manufactured by Phillystran, Inc. using coated
KevlarŪ for maximum strength.
|
|
Model R3500 Continuous Rotator
The R-3500 Universal Rotator System is
designed for medium to heavy duty antenna rotation
applications where economy, versatility and reliability are
emphasized. Designed for universal applications, the R-3500
will mount in towers with a face width as small as 18”. The
high axial load capacity of the rotator makes it suited for
top plate mounting on towers.
The rotator is supplied with a custom
designed table top controller
SHOWN WITH ROTARY JOINT, AND MOUNTED ON
18" FACE WIDTH PLATE.
See data
sheet for full details |
|
Model 1994 Ground Base
The Model 1994 Ground Base for
the Model 1990 (AS-2259) Antenna is now available. The
ground base is rated at 1kW. It is available in the original
configuration, and a heavy duty model. |
TRANSPORTABLE LOG PERIODIC ANTENNA
NSN 5985-00-009-0129
The United States Antenna Products LP-1112MR is a lightweight transportable and rotatable antenna system covering the frequency range of 4.0 to 30.0 MHz. It is designed for temporary or semi permanent installation and can be erected in less than 6 hours.. This unique antenna incorporates extremely small size for the frequency coverage. The antenna dimensions are only 62 feet (18.9 meters) (boom) by 96 feet (29.2 meters) across at the longest element. The system includes a 60 foot (18.3 meters) tower and erection system. The net weight of the system is approximately 2000 pounds (907kg).
|
|
| |
Log Periodic Systems |
United States Antenna Products, LLC of Frederick, Maryland manufactures a line of HF VHF and UHF antennas for the Military and Commercial markets. These antenna systems, formally manu-factured by Telex Communications of Lincoln Nebraska have been a standard for many years. |
 |
|
| Loop Antennas |
|
 |
Unites States Tower Services, LTD of Frederick, Maryland has acquired the Aperiodic Loop Antenna Line from Ultra Electronics of Nova Scotia, Canada. USTS has resumed production of the former Hermes Loop products under the United States Antenna Products, LLC name. Owners of Hermes Loop Antenna Systems will once again be able to obtain parts and maintenance services for their complete antenna systems.
The electronic preamplification system that makes this antenna system a leader has been completely redesigned using state of the art components. Performance has been enhanced over earlier designs. |
|
| Installation and Repair Services |
| USTS has over thirty years’ experience in erecting and servicing towers and antennas. This includes extensive experience in installation and maintenance of loop antennas, large HF stationary and rotating arrays. We also have been and will be continuing to provide full installation, maintenance, repair and reconstruction for all Telex commercial HF and VHF products. Our customers include commercial broadcasters, the military services, public safety and government entities, satellite earth station users, transportation companies and common carriers. Our services include construction, repair, refurbishment, restructuring and deconstruction of towers and antennas. |
KevlarŪ is a registered trademark of Dupont
|
